MONO-COLUMN REVOLVING GATE WITH PUSH OPEN/CLOSED

PA5014

<< Go back to prevous page

System for access control, with cloverleaf arms, operating at 230Vac controlled by the operator which selects whether to enable or disable the access of people.

Automatic barrier, with control system checking and counting people access to cinemas, theatres, playing rooms and grounds, amusements parks, roundabouts or carousels in funfairs, etc......
Revolving gate for entrance, with opening and closing of the gate controlled by push buttons.
The revolving gate has two position Open where it is free to turning or Closed where the gate is locked and the access is not allowed. The changing of the status is made by the push button.
Due to its whole stainless steel structure, it can be especially located on the outside, thanks to the suitable mechanical and electronic control system, wich do to not cause any trouble in case of all bad weathers.

Size:100X100X90
Weight:75Kg
Voltage:230V (on request 110V)
Gate Operating Voltage:24V
Command Operating Voltage:24V
Power:160W
