HIGH REVOLVING GATE FOR ENTRANCE

PA5013

<< Go back to prevous page

System for access control, with arms cloverleaf, 180cm tall model, operating at 230Vac, controlled by coin in external column. The advantage of having the coin in the external column is to have a capacity greater than tokens / coins.Automatic barrier, with control system checking and counting people access to cinemas, theatres, playing rooms and grounds, amusements parks, roundabouts or carousels in funfairs, etc.....  Due to its whole stainless steel structure, it can be especially located on the outside, thanks to the suitable mechanical and electronic control system, wich do to not cause any trouble in case of all bad weathers.

Side Bar Not Included

Gate Size:100X100X180
Column Size:17X25X96
Weight:95Kg
Voltage:230V (on request 110V)
Gate Operating Voltage:48V

Command Operating Voltage:24V
Electrical Input:12A
Power:600W


  • Slide Entrance Control
